PRODUCTS

TWT-Induction motor

Name:TWT-Induction motor



    Specification: Single phase IK induction motor     Three phase IK induction motor

                  Horsepower: 6W~180W                                                                   Horsepower: 25W~180W

                          Voltage: 100V~110V                                                                         Voltage: 200V~220V

                                         200V~220V                                                                                        380V~440V

Specialty:

Rated operation is continuous operation

Adopting E-class insulation

Single phase motors use capacitor type induction motors, resulting in high power and low noise

Three phase motors can use a three-phase power supply of 200-440V to meet various needs

■ High universality performance: can be widely used in various fields such as general household machines to production equipment automation

High reliability: The simple system structure can easily complete various operations. Induction motors and other power motors only need to be connected to capacitors and commercial power sources to operate. Simple, reliable, and long-lasting design leading the industry

■ Diverse models: The basic models include induction motors for continuous operation, reversible motors for forward and reverse transfer, as well as electromagnetic brake motors with load holding function, torque motors for pushing operation, and speed control function. The models are complete and welcome to purchase.

■ Low noise: The environment in which motors are used is constantly changing, and the requirements for low noise are becoming increasingly strict. Dongweiting motors/motors have the characteristics of low noise, high torque, small size, light weight, long service life, and maintenance free.


SINGLE PHASE 110V

Type

Output

(W)

Starting

torque

(g-cm)

Rated

torque

(g-cm)

Rated

current

(A)

Capacitor

(μF)

Appropriate reducer

Maximum

allowable load

Round shaft

Gear shaft

2IK6A-A

2IK6GN-A

6

410

370

0.2

2.5

2GN□

2GN□K

25

3IK15A-A

3IK15GN-A

15

900

900

0.34

4

3GN□

3GN□K

50

4IK25A-A

4IK25GN-A

25

1400

1500

0.48

8

4GN□

4GN□K

80

5IK40A-A

5IK40GN-A

40

2400

2500

0.7

12/14

5GN□

5GN□K

100

5IK60A-AF

5IK60GN-AF

60

3600

3700

1.2

16

5GN□

5GN□K

100

5IK60GU-AF

60

3600

3700

1.2

16


5GU□K

150

5IK90A-AF

5IK90GU-AF

90

4800

5700

1.7

25


5GU□K

200

5IK120A-AF

5IK120GU-AF

120

5200

6300

3.0

25/30


5GUCK

200

Note
Frequency (HZ)50/60Polarization Number:(P)4,Revolution(r .p .m.)1450/1750,Rated Time:Continue


SINGLE PHASE 220V

Type

Output

(W)

Starting

torque

(g-cm)

Rated

torque

(g-cm)

Rated

current

(A)

Capacitor

(uF)

Appropriate reducer

Maximum

allowable load

Round shaft

Gear shaft

2IK6A-C

2IK6GN-C

6

410

370

0.1

0.8

2GN□

2GNOK

25

3IK15A-C

3IK15GN-C

15

900

900

0.17

1.2

3GN□

3GN□K

50

4IK25A-C

4IK25GN-C

25

1400

1500

0.24

1.5

4GN□

4GNOK

80

5IK40A-C

5IK40GN-C

40

2400

2500

0.45

3

5GN□

5GN□K

100

5IK60A-CF

5IK60GN-CF

60

3600

3700

0.65

3.5

5GN□

5GN□K

100

5IK6OGU-CF

60

3600

3700

0.65

3.5


5GUOK

150

5IK90A-CF

5IK90GU-CF

90

4800

5700

0.8

5


5GUOK

200

5IK120A-CF

5IK120GU-CF

120

5200

6300

0.9

6


5GU□K

200

5IK150A-CF

5IK150GU-CF

150

6100

9545

1.3

6/8


5GUOK

200

5IK180A-CF

5IK180GU-CF

180

7000

11315

1.9

8/10


5GUOK

200

  Note: Frequency(Hz) 50/60,Pole number:(P)4, Revolution (Rpm) 1450/1750,Rated time: Continue


WIRING DIAGRAM OF SINGLE PHASE MOTOR



Three phase 220V

Type

Output

(w)

Starting

torque

(g.cm)

Rated

torque

(g.cm)

Rated

current

(A)

Capacitor

(uF)

Appropriate reducer

Maximum

allowable load

(kg.cm)

Round shaft

Gear shaft

4IK25A-S

4IK25GN-S

25

1500

1500

0.35


4GN□

4GN□K

80

5IK40A-S

5IK40GN-S

40

6500

2400

0.45

-

5GN□

5GN□K

100

5IK60A-SF

5IK60GN-SF

60

8100

3500

0.65


5GN□

5GNK

100

5IK60GU-SF

60

8100

3500

0.65



5GUK

150

5IK90A-SF

5IK90GU-SF

90

12000

5500

0.68

-

-

5GUK

200

Note:1.Frequency(Hz)50/60,Pole number:(P)4,Revolution(Rpm)1450/1750,Rated time:Continue

2.120w to 180w motor be customized

Three phase 220V/380V

Type

Output

(w)

Starting

torque

Rated

torque

(g.cm)

Rated

current

Capacitor

(uF)

Appropriate reducer

Maximum

allowable load

(kg.cm)

Round shaft

Gear shaft

4IK25A-Y

4IK25GN-Y

25

1500

1500

0.21


4GN□

4GN□K

80

5IK40A-Y

5IK40GN-Y

40

6500

2400

0.4

-

5GN□

5GN□K

100

SIK6OA-YF

5IK60GN-YF

60

8100

3500

0.4

-

5GN□

5GNK

100

5IK60GU-YF

60

8100

3500

0.4

-


5GUK

150

5IK90A-YF

5IK90GU-YF

90

12000

5500

0.46



5GUK

200

Note:1.Frequency(Hz)50/60, Pole number: (P) 4, Revolution (Rpm) 1450/1750, Rated time: Continue

2.120w to 180w motor be customized
